/ ENGINE /
Type                                       Rotax® 1330 ACE™ in-line 3 cylinders, liquid-cooled with electronic fuel injection and electronic throttle control
Bore & stroke                       3.31 x 3.14 in. (84 x 80 mm)
Power                                    115 hp (86 kW) @ 7250 RPM
Torque                                   96 lb-ft. (130 Nm) @ 5000 RPM
/ CHASSIS /
Front suspension                Double A-arms with anti-roll bar
Front shocks type / Travel  SACHS† Big-Bore shock absorbers / 5.1 in. (129 mm)
Rear suspension                Swing-arm with basic monoshock
Rear shock type / Travel    SACHS shock absorber / 5.2 in. (132 mm)
Electronic brake                  Foot-operated, hydraulic 3-wheel brake distribution system
Front brakes                        270 mm discs with Brembo† 4-piston fixed calipers
Rear brake                           270 mm disc, 1-piston floating caliper with integrated parking brake
Parking brake                      Electrically actuated
Front tires                             MC165 / 55R15 55H
Rear tire                                MC225 / 50R15 76H
Aluminum front rims           6-spoke, Machined Deep Black high gloss front wheels, 15 x 5 in. (381 x 127 mm) Aluminum rear rim Deep Black, 15 x 7 in. (381 mm x 178 mm)
/ FEATURES /
Instrumentation                  Premium color digital gauge: Digital speedometer, tachometer, odometer, trip & hour meters, gear position, ECO™ mode smart assist,                                                temperature, engine lights, electronic fuel gauge, clock Running lights 2 halogen headlamps (55 / 60-W)
Windshield Tinted
Cruise control Electronic
RT-622 and Freedom Towing capacity of 400 lb (181 kg) trailer capability
Trims and parts                Chrome Satin and Carbon Black: Rear sprocket wheel, front and rear shocks springs, exhaust tip and heat shield
/ SAFETY & SECURITY /
SCS Stability Control System
TCS Traction Control System
ABS Anti-lock Braking System
DPS™ Dynamic Power Steering
Anti-theft system Digitally Encoded Security
System (D.E.S.S.™)
/ DIMENSIONS /
L x W x H                             102.2 x 58.9 x 48.9 in. .(2,596 x 1,497 x 1,241 mm)
Wheelbase                         67.3 in. (1,709 mm)
Seat height                         26.6 in. (675 mm)
Ground clearance             4.5 in. (115 mm)
Dry weight                           948 lb (430 kg)
Storage capacity                20.6 gal (78 L)
Maximum vehicle load     439 lb (199 kg)
Fuel capacity                     7.1 gal (27 L)
Reserve                             1.2 gal (4.5 L) approx.
Fuel type Premium unleaded
/ WARRANTY /
Factory 2-year BRP Limited Warranty
with 2-year roadside assistance

ALL SPYDER F3 LIMITED FEATURES PLUS:
6-spoke, Black Chrome front wheels
Black perforated seat with Black stitching
Exclusive Triple Black coloration and graphics
Unique Special Series signature trims
TRANSMISSION AND COLOR AVAILABLE:
6-speed semi-automatic with reverse (SE6)
SPYDER F3 LIMITED SPECIAL SERIES
Rotax 1330 ACE in-line 3 cylinders, high torque engine
Vehicle Stability System with ABS, traction control and stability control
High-performance Brembo† braking system
SACHS Big-Bore shock absorbers
ECO™ mode smart assist
UFit custom fitting system
(rider footpegs and handlebars)
Anti-theft system
Dynamic Power Steering
Refined front fenders with integrated LED lights
6-spoke, Machined deep black high gloss front wheels
Rider and passenger Black perforated seat with Red stitching
Integrated hard side luggage
Convenience console including tinted windshield,
integrated rear view mirror and glove box
Trailer ready
Premium color digital gauge
Optional 4-speaker audio system with USB port
©2015 Bombardier Recreational Products Inc. (BRP). All rights reserved. ®, ™ and the BRP logo are trademarks of Bombardier Recreational Products Inc. or its affiliates. Products are
distributed in the U.S.A. by BRP US Inc. †All other trademarks are the property of their respective owners. Always ride responsibly and safely. Follow all instructional and safety materials.
Always observe applicable local laws and regulations. Always wear a helmet, eye protection and appropriate protective clothing. And always remember that riding and alcohol/drugs don’t mix. BRP reserves
the right, at any time, to discontinue or change specifications, prices, designs, features, models or equipment without incurring obligation. Some models depicted may include optional equipment. Vehicle
performance may vary depending on weather, temperature, altitude, riding ability and rider/passenger weight.
SPYDER F3-T
ALL SPYDER F3-T FEATURES PLUS:
Audio system: 4 speakers (2 – 4 1/2" + 2 – mid-range 2 1/2" woofers)
comes with USB port located in the glove box
and aux. plug (Jack 1/8) for cell and MP3 player
Rider heated grips
Rider footboards
Shamrock Chrome front wheels
Chrome trims
Limited trim signature seat
Rider and passenger Black embossed suede
comfort seat with stitching
SPYDER F3 LIMITED
STANDARD FEATURES
PACKAGE OPTIONS
TRANSMISSIONS AND COLORS AVAILABLE:
6-speed manual with reverse (SM6)
6-speed semi-automatic with reverse (SE6)
TRANSMISSION AND COLORS AVAILABLE:
6-speed semi-automatic with reverse (SE6)
canamspyder.com
MONOLITH BLACK
SATIN
PEARL WHITE
STEEL BLACK
METALLIC
PURE MAGNESIUM
METALLIC
WITH CAN-AM RED
FRAME
INTENSE RED
PEARL
PEARL WHITE
STEEL BLACK
METALLIC
INTENSE RED
PEARL
